Economical Modulated RF Power Amplifiers For Pre-Compliance Testing
The TekBox TBMDA2/TBMDA3 Modulated Wideband Power Amplifiers are designed to create an inexpensive signal source for pre-compliance immunity testing of electronic PCBs and products. Driven by the tracking generator output of a spectrum analyzer, they provide the increased RF power outputs required by many test environments. With an input power range of up to -8dBm…
Real-Time Spectrum Analyzer With Maximum Sample Rate Of 51.2MS/s
Saelig Company, Inc. announced the availability of the Rigol Technologies RSA5000 Series of RF spectrum analyzers. These real-time devices scan a complete frequency spectrum of 9kHz to 3.2 or 6.5GHz with a maximum sample rate of 51.2MS/s. They offer significant performance improvements over traditional swept spectrum analyzers with a 1ms full span sweep, an expanded vertical…
Spectrum Analyzer Capable Of Completing Scans Up To 9 kHz
Saelig Company, Inc. announced the availability of the Rigol Technologies RSA5000 Series of RF spectrum analyzers. These real-time devices scan a complete frequency spectrum of 9kHz to 3.2 or 6.5GHz with a maximum sample rate of 51.2MS/s. They offer significant performance improvements over traditional swept spectrum analyzers with a 1ms full span sweep, an expanded vertical…
RF USB That Functions Like A Benchtop Spectrum Analyzer
Saelig Company, Inc. has announced the availability of the VSA6G2A Vector Spectrum Analyzer – an economical USB RF tool that plugs into the USB port of a PC and is controlled with the provided PC application software. It offers almost all of the functionality of a benchtop spectrum analyzer. Its frequency range of operation is from 100Hz…
EMI Tent Enclosure Perfect Device For Benchtop Precompliance Tests
The TekBox TBST120/60/60/2 Shielded Tent, which provides an economical RF/EMI-attenuated environment for a variety of bench-top “EMI quiet” applications. The TBST-120/60/60/2 is a compact shielded tent, designed to suppress interference from ambient noise during EMC pre-compliance measurements. With outer dimension of 4’ x 2’ x 2’ it can accommodate pre-compliance test equipment such as LISNs…
Four-Channel Oscilloscope Series Enters New Generation Of Technology
The Siglent SDS1104X-E (100MHz) and Siglent SDS1204X-E (200MHz) are four-channel oscilloscopes that are built on the same platform as the very popular SDS1202X-E but with many improvements, including two 1GSa/s ADCs and two 14Mpt memory modules. Waveform capture rates are up to 100,000wfms/s in normal mode and 400,000wfms/s in sequence mode. The SDS1000X-E scopes feature…
Waveform Generators With Advanced Dual-Channel Capabilities
Siglent’s SDG6000X series of Dual-Channel Pulse/Arbitrary Waveform Generators create test signals up to 500MHz using a sample rate of 2.4GSa/s and 16-bit vertical resolution for an 80dB dynamic range. This series features Siglent’s proprietary TrueArb and EasyPulse technologies that solve the weaknesses inherent in traditional DDS waveform creation. TrueArb technology generates arbitrary waveforms “point-by-point” to…
Scope-In-A-Probe Offers 30 MHz Bandwidth
The IkaScope WS200 from Saelig is a pen-shaped battery-powered wireless oscilloscope that streams captured signals to almost any WiFi-connected screen. The IkaScope WS200 offers a 30 MHz bandwidth with its 200 MSa/s sampling rate and the maximum input is +/-40 Vpp. It provides galvanically-isolated measurements even when a USB connection is charging the internal battery.…
Economic, USB-Controlled, Low-Cost Vector Network Analyzer An Industry First
Saelig Company, Inc. has introduced the Pico Technology PicoVNA 106 Low-Cost Vector Network Analyzer – an economical USB-controlled, professional-grade 300kHz to 6GHz Vector Network Analyzer (VNA) with excellent performance, portability, and affordability. Despite its small size and low cost, its full-function, minimal-error, ‘Quad RX’ four-receiver architecture supports both 8- and 12-term calibration without the uncorrectable…
